PET monofilament braided Expandable Sleevings for automobile wire cables
ABOUT PRODUCT
31.8MM Black Nylon Multifilament Braided Sleeving for Fishing Rod is braided with environment-friendly polyester monofil. (PET, PA6, PA66, PPS), It possesses good flexibility, fire resistance, abrasive resistance and thermal insulation performance. The sleeving owns smooth surface, bright color, various patterns.
CHARACTERISTICS
1. high temperature resistant (working temperature: -50°c ~ 150°c) 2. high melting point (250°c) 3. high fire resistant performance 4. flexible, abrasive resistance, thermal insulation
WORKING TEMPERATURE
-50°c ~ 150°c
SPECIFICATION
| Part No. | Model No. | Min Width (mm) | Max Width(mm) | Part No. | Model No. | Min Width(mm) | Max Width (mm) |
| 24# | 120024 | 3 | 6 | 56# | 120056 | 8 | 16 |
| 125024 | 3 | 6 | 125056 | 8 | 16 |
| 320024 | 4 | 8 | 320056 | 10 | 20 |
| 325024 | 4 | 8 | 325056 | 10 | 20 |
| 32# | 120032 | 4 | 8 | 64# | 120064 | 9 | 18 |
| 125032 | 4 | 8 | 125064 | 9 | 18 |
| 320032 | 5 | 10 | 320064 | 12 | 24 |
| 325032 | 5 | 10 | 325064 | 12 | 24 |
| 36# | 120036 | 5 | 10 | 72# | 120072 | 10 | 12 |
| 125036 | 5 | 10 | 125072 | 10 | 12 |
| 320036 | 6 | 12 | 320072 | 15 | 30 |
| 325036 | 6 | 12 | 325072 | 15 | 30 |
| 40# | 120040 | 6 | 12 | 96# | 120096 | 12 | 24 |
| 125040 | 6 | 12 | 125096 | 12 | 24 |
| 320040 | 7 | 14 | 320096 | 20 | 40 |
| 325040 | 7 | 14 | 325096 | 25 | 50 |
| 48# | 120048 | 7 | 14 | 120# | 120120 | 15 | 30 |
| 125048 | 7 | 14 | 125120 | 15 | 30 |
| 320048 | 8 | 16 | 320120 | 30 | 70 |
| 325048 | 8 | 16 | 325120 | 35 | 100 |
APPLICATION 31.8MM Black Nylon Multifilament Braided Sleeving for Fishing Rod is widely used in bounding and protecting of electrical cables, automobile and aviation sectors. The selection of this product refers to following four parameters.
A- yarn number (one or three);
B- Diameter of single yarn (0.25mm or 0.20mm)
C- Strand number (48 spindles braiding machine or 72 spindles braiding machine) D- flat width(6mm or 18mm)
